Coupling

A coupling is a mechanical element part that connects two shafts together to accurately transmit the power from the drive side to the driven side while absorbing the mounting error (misalignment), etc. of the two shafts.

Coupling in the machine industry is interpreted as "a part that connects two shafts together", and is generally called "coupling", "shaft coupling" or "joint".

Size Range

Outer Diameter 6mm ~273mm
Wall Thickness 0.7mm ~25mm
Length 1 ~18mtr

Within this range pipes/tubes of any size can be produced

Production Standards

ASTM A53, ASTM A106, ASTM A179,ASTM A192, ASTM A199, ASTM A210, ASTM A213, ASTM A333, ASTM A334,
ASTM A335, ASTM A519
API 5L, API 5CT
DIN 2391, DIN 2440, DIN 2441, DIN 2448, DIN 1629, DIN 1630, DIN 17173/2448, DIN 17175/2448
JIS G3464, JIS G3444
BS1387, BS3059/1, BS3059/2, BS1775, BS6323
NFA49-112, NFA49-1445, NFA49-211
UNI 8863

Test Performed

Destructive Test : Tensile, Flattening, Flaring, Bending
N.D.T : Hydrostatic Test, Eddy Current Test, chemical Analysis
Others as required by the standard or customer

Test Certificate

Pipes/tubes are delivered with certificates as per required standard

Marking

On Pipe surface (Die Stamp or paint Stencil) On bundles (Metal Label or Plastic Label)

Packaging

in bundles

• Special packing on request

Despatch

It is done with a suitable mode of transport, so that the products is delivered in proper condition

LIST OF MEASURING INSTRUMENTS :

Sr.No.	INSTRUMENT NAME	MAKE	RANGE	QTY
1	PLUNGER DIAL	BAKER	0-10 mm	10
2	PLUNGER DIAL	BAKER	0-1 mm	2
3	OUTSIDE MICROMETER	Mitutoyo	0-25 mm	1
4	OUTSIDE MICROMETER	Mitutoyo	25-50 mm	2
5	OUTSIDE MICROMETER	Mitutoyo	50-75 mm	3
6	OUTSIDE MICROMETER	Mitutoyo	75-100 mm	4
7	Digital Vernier Caliper	BAKER	0-200 mm	4
8	Digital Vernier Caliper	BAKER	0-300 mm	1
9	Vernier Caliper	Mitutoyo	0-300 mm	1
10	Digital Vernier Caliper	BAKER	0-300 mm	2
11	Bore Dial Gauge	BAKER	50-160 mm	1
12	Surface Plate	Jafuji	400 X 400 mm	1
13	Leaver Plunger Dial	BAKER	0-0.14 mm	1
14	Thread Work Plug Gauge	LONE STAR	2-3/8" EUE	2
15	Thread Work Plug Gauge	LONE STAR	2-7/8" EUE	2
16	Thread Work Plug Gauge	Size Control	3-1/2" EUE	1
17	Thread Work Plug Gauge	Size Control	4-1/2" EUE	1
18	Thread Work Plug Gauge	Size Control	5-1/2" LTC	1
19	Thread Lead Gauge	Gagemaker	½”-4” Thread Lead	1
20	Thread Taper Gauge	Gagemaker	4-¼” Depth     1- ½”-9” Dia	1
21	Thread Taper Gauge	Gagemaker	0-0.0005”            8RD	1
22	Profile Template	Gagemaker	8 & 10     TPI Standard	1
23	Bench Center	Luttra	0-600 mm	1

LIST OF MACHINES :

Sr. No.	Machine Name	Make	Capacity	Qty
1	CNC Machine	SPM, India	Chuck Dia- 200 mm Max. Turning Dia- 300 mm Max Turning Length- 500 mm	1
2	CNC Machine	ACE Classic, LT20	Chuck Dia- 250 mm Max Turning Dia -300 mm Max Turning Length- 630 mm	1
3	CNC Machine	Macpower	Chuck Dia- 200 mm Max. Turning Dia- 300 mm Max turning length- 550 mm	1
4	CNC Machine	Jyoti CNC	Chuck Dia- 200 mm Max. Turning Dia- 300 mm Max turning length- 550 mm	1
5	CNC Machine	ACE Jobber XL	Chuck Dia- 200 mm Max. Turning Dia- 300 mm Max turning length- 550 mm	1
6	Lathe Machine	B. Parmar	Bed- 9 Ft Power-5 HP Spindle Bore- 110 mm	2
7	Lathe Machine	B. Parmar	Bed- 7 Ft Power-5 HP Spindle Bore- 53 mm	1
8	Lathe Machine	B. Parmar	Bed- 4.5 Ft Power-5 HP Spindle Bore- 105 mm	2
9	Lathe Machine	B. Parmar	Bed- 12 Ft Power-5 HP Spindle Bore- 110 mm	1
10	Bandsaw Machine	Rajlaxmi	Blade Size- 3505 mm Power-1.5 HP	2
11	Automatic Bandsaw Machine	Shivprabhu	Blade Size- 3760 mm Power-3 HP	1
12	MPI Machine	Mayuresh	Capacity- 3000 A	1

LIST OF CUSTOMERS :

Sr. No.	CUSTOMER	LOCATION
1	I.S.M.T. LTD	AHMEDNAGAR
2	TECHNO TRAK ENGINEERS	AHMEDNAGAR
3	ENERGY OILFIELD TOOLS PVT LTD	DELHI
4	FORCAS IMPEX PVT. LTD.	AHMEDNAGAR
5	SAP PARTS	PUNE
